The System p, formerly known as RS/6000, was IBM's RISC/UNIX-based server product line.

• Ibm System P5 Serial Connection Baudelaire
• Rs232 Serial Connection
• Ibm System P5
• What Is A Serial Connection
• Nortel Cpmgs Card Serial Connection Baud Rate
• Usb To Serial Connection
• Ibm System P5 Serial Connection Baud

In April 2008, IBM announced a rebranding of the System p and its unification with the System i platform. The resulting product line is called IBM Power Systems.

• 4Models

Accessing the Advanced System Management Interface [pic.dhe.ibm.com] Old Apps. Steps to Boot or Reboot an IBM P5 into AIX: Login to the HMC using serial connection. IBM eServer P5 520. The IBM eServer POWER5 520 (referred to hereafter as the P5 520 when discussing the DR550) is a cost-effective, high performance, space-efficient server that uses advanced IBM technology. The P5 520 uses the POWER5 microprocessor, and is designed for use in LAN clustered environments.

How to connect to an IBM Power5 server through a Serial Cable. How to connect to an IBM Power5 server through a Serial Cable and PuTTY. Complete User Registration system using PHP and MySQL. IBM System p5 Solution Edition Express configurations are intended to be used in conjunction with one of these participating application environments. The IBM System p5 Solution Editons employ the same configuration rules as the Express Product Offerings. IBM System p5 520 minimum system configuration. This 8 meter cable is available to provide a null-modem connection between the serial ports of two system drawers that are mounted in separate racks. The serial port design on the p5 Servers requires special considerations when used for other applications while an HMC is attached. 'Dear sir does any one know how to log into an IBM 9131-52a p5 series server via the serial ports at the front. The system isn't managed by a HMC. I've tried Hyper term & net Term with a serial cable at 9600,8,n,1 & 3151 emulation & vt100 with my laptop and also changed the com ports but invain. I am unable to login serial connection. Serial cable.

History[edit]

RS/6000 was originally a line of workstations and servers. The server line was then renamed to the eServer pSeries in 2000 as part of its e-Server branding initiative.

In 2004, with the advent of the POWER5 processor, the family was rebranded the eServer p5.In 2005, following IBM's move to streamline its server and storage brands, worldwide, and incorporating the System brand, with the Systems Agenda, the family was renamed yet again as System p5.

The System p5 now encompasses the IBM OpenPower product line.After the introduction of POWER6 processor models, the new models were released under the System p brand, dropping the p (numbered) designation.

Processors[edit]

Whereas RS/6000 used a mix of early POWER and PowerPC processors, when pSeries came along this had evolved into RS64-III and POWER3 across the board—POWER3 for its excellent floating-point performance and RS64 for its scalability, throughput, and integer performance.

IBM developed the POWER4 processor to replace both POWER3 and the RS64 line in 2001. After that the differences between throughput and number crunching-optimized systems no longer existed. Since then System p machines evolved to use the POWER5 but also the PowerPC 970 for the low-end and blade systems.

The last System p systems used the POWER6 processor, such as the POWER6-based System p 570 and the JS22 blade. In addition IBM introduced during the SuperComputing 2007 (SC07) conference in Reno a new POWER6-based System p 575 with 32 POWER6 cores at 4.7 GHz and up to 256 GB of RAM with water cooling.

Features[edit]

All IBM System p5 and IBM eServer p5 machines support DLPAR (Dynamic Logical Partitioning) with Virtual I/O and Micro-partitioning.

System p generally uses the AIXoperating system and, more recently, 64-bit versions of the Linux operating system.

Models[edit]

BladeCenter[edit]

• IBM BladeCenter JS12 (POWER6)
• IBM BladeCenter JS22 (POWER6)
• IBM BladeCenter JS23 (POWER6)
• IBM BladeCenter JS43 (POWER6)

pSeries[edit]

• IBM eServer pSeries 610 (7028-6C1 & 6E1)
• IBM eServer pSeries 615 (7029-6C3, 7029-6E3) 1-2 POWER4 CPUs
• IBM eServer pSeries 620 (7025-F80, 6F0 & 6F1)
• IBM eServer pSeries 630 (7028-6C4, 7028-6E4) 1-4 POWER4 CPUs
• IBM eServer pSeries 640 (7026-B80) 1-4 POWER3-II CPUs
• IBM eServer pSeries 650 (7038-6M2) 2-8 POWER4 CPUs
• IBM eServer pSeries 655 (7039-651) 4-8 POWER4 CPUs
• IBM eServer pSeries 660 (7026-H80, 6H0, 6H1, M80 & 6M1)
• IBM eServer pSeries 670 (7040-671) 4-16 POWER4 CPUs
• IBM eServer pSeries 680 (7017 range)
• IBM eServer pSeries 690 (7040-681) 8-32 POWER4 CPUs

The IBM p690 was, at the time of its release in late 2001, the flagship of IBM's high end Unix servers (pSeries) during the POWER4 era of processors. It was built to run IBM AIX Unix, although it is possible to run a version of Linux minus some POWER4 specific features. It was discontinued in late 2005.^[1]

It can support up to thirty-two 1.50, 1.70 or 1.90 GHz POWER4+ processors and 1 TB of RAM. It weighs well over 1000 kg. It was used in a supercomputer at Forschungszentrum Jülich in 2004.

System p[edit]

System p was rebranded Power Systems in 2008.

• IBM System p 520 Express (POWER6)
• IBM System p 550 Express (POWER6)
• IBM System p 560 Express (POWER6)
• IBM System p 570 (POWER6)
• IBM System p 575 (POWER6)
• IBM System p 595 (POWER6)
• IBM System p5 505
• IBM System p5 505Q
• IBM System p5 510 (9110-510) 1-2 POWER5 CPUs
• IBM System p5 510 (9110-51A) 1-2 POWER5+ CPUs
• IBM System p5 510Q (9110-51A) 4 POWER5+ CPUs
• IBM System p5 520 (9111-520) 1-2 POWER5 CPUs
• IBM System p5 520Q
• IBM System p5 550 (9113-550) 1-4 POWER5 CPUs
• IBM System p5 550 Express(1.9G, 2.1G)
• IBM System p5 550Q
• IBM System p5 550Q Express (4-8 cores POWER5+ CPUs) (Model 9133-55A)
• IBM System p5 560Q
• IBM System p5 570 (9117-570) 2-16 POWER5 CPUs
• IBM System p5 575 (9118-575) 8-16 POWER5 CPUs
• IBM System p5 590 (9119-590) 8-32 POWER5 CPUs
• IBM System p5 595 (9119-595) 16-64 POWER5 CPUs

OpenPower[edit]

OpenPower was the name of a range of servers in the System p line from IBM. They featured IBM's POWER5CPUs and run only 64-bit versions of Linux. IBM's own UNIX variant, AIX is not supported since the OpenPower servers are not licensed for this operating system.

There were two models available, with a variety of configurations.

Before 2005, OpenPower belonged to the eServer product line but were eventually rolled into the IBM's Power Systems product portfolio.

• IBM eServer OpenPower 710 (9123-710) 1-2 POWER5 CPUs
• IBM eServer OpenPower 720 (9124-720) 1-4 POWER5 CPUs

IntelliStation POWER[edit]

• IBM IntelliStation POWER 185 (PowerPC 970)

BladeCenter[edit]

• IBM BladeCenter JS20 (PowerPC 970)
• IBM BladeCenter JS21 (PowerPC 970)

See also[edit]

• Web-based System Manager, an AIX management software
• IBM Hardware Management Console, a management appliance

References[edit]

This article is based on material taken from the Free On-line Dictionary of Computing prior to 1 November 2008 and incorporated under the 'relicensing' terms of the GFDL, version 1.3 or later.

1. ^'pSeries 690'. IBM. 2005-11-08. Retrieved 2014-02-10.

External links[edit]

• IBM launches POWER5-based p5 server line – Ars Technica, 14 July 2004

IBM® TotalStorage® DR550 SMB

Installation, Setup, Operations, and

Problem Determination Guide

(P) IBM part number: 95P2745

*P95P2745*

(2P) EC Level: H81631

*2PH81631*

Introduction

IBM® TotalStorage® DR550 SMB, one of IBM’s Data Retention offerings, is an integrated offering for clients that need to retain and preserve electronic business records. The DR550 SMB packages storage, server and software retention components into a preconfigured offering.

Integrating IBM eServer™ pSeries® POWER5™ processor-basedservers and IBM Tivoli® Storage Manager for Data Retention software, this offering is designed to provide a central point of control to help manage growing compliance and data retention needs. The powerful system, which is designed to be mounted into a standard 19 inch rack (you may want to consider a lockable rack for added security - the cabinet is not included with DR550 SMB, but can be purchased separately if needed), supports the ability to retain data and prevents tampering or alteration. The system’s compact design can help with fast and easy deployment, and incorporates an open and flexible architecture.

To help clients better respond to changing business environments as they transform their infrastructure, the DR550 SMB is shipped with approximately 1 terabyte of physical capacity and can expanded (add an additional 1 TB) as needs require.

IBM TotalStorage Data Retention Innovative Technology

At the heart of the offering is IBM Tivoli Storage Manager for Data Retention. This new industry changing software is designed to help customers protect the integrity of data as well as automatically enforce data retention policies. Using policy-basedmanagement, data can be stored indefinitely, can be expired based on a retention event, or have a predetermined expiration date. In addition, the retention enforcement feature may be applied to data using deletion hold and release interfaces which hold data for an indefinite period of time, regardless of the expiration date or defined event.

The policy software is also designed to prevent modifications or deletions after the data is stored. With support for open standards, the new technology is designed to provide customers flexibility to use a variety of content management or archive applications.

Tivoli Storage Manager for Data Retention is installed in the IBM eServer P5 520 using POWER5 processor. This entry-levelserver has many of the attributes of IBM’shigh-endservers, representing outstanding technology advancements.

Tape storage can be critical for long-termdata archiving, and IBM provides customers with a comprehensive range of tape solutions. The IBM TotalStorage DR550 SMB supports IBM's TotalStorage Enterprise Tape Drive 3592 (including the new Write Once Read Many or WORM cartridges) as well as the IBM Linear Tape Open family of tape products and other tape brands. Due to the permanent nature of data stored with the DR550, it is strongly recommended that the 3592 with WORM cartridges be used to take advantage of tape media encoded to enforcenon-rewriteandnon-erasecapability. This complementary capability will be of particular interest to customers that need to store large quantities of electronic records to meet regulatory and internal audit requirements.

The DR550 SMB is available in two basic configurations: disk only (which can be enhanced later to connect tape) and disk and tape ready (all connections for both disk and tape are included in the solution).

Hardware Overview

The DR550 SMB includes one IBM eServer P5 520 server running AIX® 5.2, a flat panel monitor and keyboard, and when configured for tape attachment, a Fibre Channel SAN Switch is included in the offering. No clustering option is available.

IBM eServer P5 520

The IBM eServer POWER5 520 (referred to hereafter as the P5 520 when discussing the DR550) is a cost-effective,high performance,space-efficientserver that uses advanced IBM technology. The P5 520 uses the POWER5 microprocessor, and is designed for use in LAN clustered environments.

The P5 520 is a member of the symmetric multiprocessing (SMP) UNIX servers from IBM. The P5 520 (product number 9111-520)is a4-EIA(4U),19-inchrack-mountedserver (you will need ton provide space in an existing rack or purchase a new rack separately). The P5 520 is configured with a1-way1.5 GHz processor. The total system memory installed is 512 MB.

The P5 520 includes six hot-plugPCI-Xslots, an integrated dual channel Ultra320 SCSI controller, two 10/100/1000 Mbps integrated Ethernet controllers, and eightfront-accessibledisk bays supportinghot-swappabledisks (all eight are populated with 146 GB Ultra3 10K RPM disk drives). These disk bays are designed to provide high system availability and growth by allowing the removal or addition of disk drives without disrupting service. The internal disk storage usesRAID-5protection for high availability.

In addition to the disk drives, there are also 3 media bays available.

• Media - dev0 – not used for DR550

•Media – dev1 – Slimline DVD-RAM(FC 5751)

•SCSI tape drive (not included)

From the back of the server, the following ports and slots are included.

PCI-X slots: The P5 520 provides multiplehot-plugPCI-Xslots. The number and type of adapters installed is dependent on the configuration selected.

Disk only version: The following adapters are installed.

• One – POWER GXT135P Graphics Accelerator with Digital support adapter (FC 2849)o Used to connect to the integrated monitor

The customer will need to choose one of the following adapters for network connection.

•For fiber optic connections, choose the single Port Gigabit Ethernet-SXPCI-Xadapter (feature code 5701).

•For copper connections, use the integrated 10/100/1000 Ethernet ports on the p520 server.

Disk and Tape ready version: The following adapters are installed.

•One 2 Gigabit Fibre Channel PCI-Xadapters (two for connections to the internal SAN for disk attachment and one for connection to the internal SAN for tape attachment) (FC 5716)

•One – POWER GXT135P Graphics Accelerator with Digital support adapter (FC 2849)

o Used to connect to the integrated monitor

The customer will need to choose one of the following adapters for network connection.

•For fiber optic connections, choose the single Port Gigabit Ethernet-SXPCI-Xadapter (feature code 5701).

•For copper connections, use the integrated 10/100/1000 Ethernet ports on the p520 server.

I/O ports: The P5 520 includes several native I/O ports as part of the basic configuration:

•2 10/100/1000 Ethernet ports (for copper based connections) – these are used to for connection to the external customer network

•2 serial ports (RS232).

oThese are not used with DR550 SMB

•2 USB ports

oOne of these is used to connect to the keyboard and mouse

•2 RIO ports

oThese are not used by DR550 SMB

•2 HMC (Hardware Management Console) ports

oThese are not used by DR550 SMB

•2 SPCN ports

oThese are not used by DR550 SMB

The Converged Service Processor2 (CSP) is on a dedicated card plugged into the main system planar, which is designed to continuously monitor system operations, taking preventive or corrective actions to promote quick problem resolution and high system availability.

Additional features are designed into pSeries servers to provide an extensive set of reliability, availability, and serviceability (RAS) features such as improved fault isolation, recovery from errors without stopping the system, avoidance of recurring failures, and predictive failure analysis.

Additional information on the P5 520 server is available at www.ibm.com/redbooks.

Management Console

Included in the DR550 SMB is an integrated flat panel monitor, keyboard and mouse. The IBM 7316-TF3is arack-mountedflat panel console kit consisting of a 17 inch (337.9 mm x 270.3 mm) flat panel color monitor, rack keyboard tray, IBM travel keyboard (English only), and the Netbay LCM switch. This is packaged as a 1U kit and can be mounted in a customer provided rack along with the other DR550 SMB components. The Netbay LCM Switch is mounted in the same rack space, located behind the flat panel monitor. The IBM Travel Keyboard is configured for English. An integrated “mouse” is included in the keyboard. The POWER5 520 server is connected to the Netbay LCM switch so that the monitor and keyboard can access the server.

IBM TotalStorage SAN Switch

One IBM TotalStorage SAN Fibre Channel Switch is included in the offering if the “disk and tape ready” option is ordered. The switch is used to interconnect the P5 520 server with fibre channel based tape solution such as the IBM 3592. The switch (2005-H08)supports multiple connections ot the tape.

The 2005-H08is an8-port,dual speed,auto-sensingfibre channel switch. Four ports are populated with 2 gigabit shortwave transceivers when the DR550 SMB is configured for disk and tape.

IBM SAN Fibre Channel Switch 2005-H08

Accessing the Switch(es)

If you need to access the switch(es) to review the zoning information, error messages, or other information, you will need to connect Ethernet cables (provided by the customer) to the Ethernet port on the switch. These cables would also need to be connected to the customer network. You can then access the switch using the IP address. The Userid is ADMIN and the password is PASSWORD. You should change this password to confirm with site security guidelines.

If you should need to review the configuration or zoning within the switches, the IP address for the switch is 192.168.1.31. This address should not be changed. To gain access to the switch via the IP network, you will need to provide an Ethernet cable and ports on your existing Ethernet network. Once the connections have been made, then you can connect to the IP address and use the management tools provided by the switch.

The zoning used with DR550 SMB is the default zoning shipped with the switch. That is, one zone for all 8 ports.

For more information, 2005-H08data sheets can be downloaded from:http://www.storage.ibm.com/ibmsan/products/2005/h08/pdf/datasheet.pdf

Software Overview

Tivoli Storage Manager for Data Retention

IBM Tivoli Storage Manager for Data Retention provides enhancements to IBM Tivoli Storage Manager Extended Edition (hereafter referred to as Tivoli Storage Manager) designed to prevent critical data from being erased or rewritten. This new product can help address requirements defined by many regulatory agencies for retention and disposition of data. These enhancements include new functionality and new device support and are delivered in these key areas:

•Data retention protection This feature is designed to prevent deliberate or accidental deletion of data until its specified retention criterion is met. See “Data Retention Protection” for more information.

•Event-based retention policy - In some cases, retention must be based on an external event such as closing a brokerage account. Tivoli Storage Manager for Data Retention supportsevent-basedretention policy to allow data retention to be based on an event other than the storage of the data. See “Defining and Updating an Archive Copy Group” for more information.

•Deletion hold In order to ensure that records are not deleted when a regulatory retention period has lapsed but other requirements mandate that the records continue to be maintained, Tivoli Storage Manager for Data Retention includes deletion hold. Using this feature will help prevent stored data from being deleted until the hold is released. See “Deletion Hold” for more information.

•Data encryption - 128-bit Advanced Encryption Standard (AES) is now available for the Archive API Client. Data can now be encrypted before transmitting to the DR550 and would then be stored on the disk/tape in an encrypted format.

For more information on Tivoli Storage Manager for Data Retention and Tivoli Storage Manager Extended Edition, refer to the Tivoli Storage Manager for AIX Version 5.3 Administrator’s Guide, Administrator’s Reference and Quick Start manuals which can be found on the web at: http://publib.boulder.ibm.com/infocenter/tivihelp/index.jsp?toc=/com.ibm.itstorage.doc/toc.xml

Select TSM for AIX and then the Administrator’s Guide

Tivoli Storage Manager API Client

The Tivoli Storage Manager API Client is used, in conjunction with Tivoli Storage Manager for Data Retention, as the link to applications that produce or manage information to be stored, retrieved and retained. Content management applications, such as The IBM DB2® Content Manager, identify information to be retained. The content management application calls the Tivoli Storage Manager Archive API Client to store, retrieve and communicate retention criteria to the Tivoli Storage Manager server. The Tivoli Storage Manager API Client must be installed on the application or middleware server that is used to initiate requests to DR550 SMB. The application or middleware server must call the Tivoli Storage Manager API to initiate a task within the DR550 SMB.

Some applications and middleware include the API client as part of their code. Others require it to be installed separately.

Content Management Applications

For the DR550 SMB to function within a customer IT environment, information appropriate to be retained must be identified and supplied to the DR550 SMB. This can be accomplished with a content management application. The content management application identifies information appropriate to be retained, and provides this information to the DR550 SMB via the Tivoli Storage Manager API Client.

IBM DB2 Content Manager

To assist customers in addressing needs for data retention, IBM delivers DB2 Content Manager along with business consulting services (as needed).

IBM® DB2® Content Manager provides a foundation for managing, accessing and integrating critical business information on demand. It lets you integrate all forms of content - document, web, image, rich media - across diverse business processes and applications, including Siebel, PeopleSoft and SAP. Content Manager integrates with existing hardware and software investments, both IBM and non-IBM,enabling customers to leverage common infrastructure, achieve a lower cost of ownership, and deliver new, powerful information and services to customers, partners and employees where and when needed. It is comprised of two core repository products that are integrated with Tivoli Storage Manager for storage of documents into the DR550:

•DB2 Content Manager is optimized for large collections of large objects. It provides imaging, digital asset management, and web content management. When combined w/ DB2 Records Manager, it also provides a robust records retention repository for managing the retention of all enterprise documents.

•DB2 Content Manager OnDemand is optimized to manage very large collections of smaller objects such as statements and checks. It provides output and report management.

More information on the DB2 Content Manager portfolio of products can be found at the following web site: http://www-306.ibm.com/software/data/cm/

There are a number of applications that work with IBM Content Manager to deliver specific solutions. These applications are designed to use Content Manager functions and can send data to be stored in DR550 SMB.

Other Management Applications

Consult with your application software vendor to determine if the application supports the Tivoli Storage Manager API Client for data archive in a Tivoli Storage Manager for Data

Retention environment. Several vendors have qualified (or have committed to qualify) one or more of their applications with DR550 SMB. Some of these vendors include Ceyoniq, Comprendium, Easy Software, Hummingbird Ltd, Hyperwave, IRIS Software, IXOS Software, KVS, a business unit of VERITAS software, Neeb and Partner, OuterBay Technologies, Princeton Softech, SAPERION, SER Solutions, and Waters.

Only applications or middleware using the API can send data to DR550 SMB. Information regarding the

Tivoli Storage Manager API Client may be found at publib.boulder.ibm.com/infocenter/tivihelp/index.jsp?toc=/com.ibm.itstorage.doc/toc.xml

Additional information on qualified ISVs may be found at http://www.ibm.com/storage/dr550

DR550 SMB

DR550 SMB is available as a single node offering. The offering can also be customized to include support for tape, and the appropriate Ethernet connections.

DR550 SMB Components

The DR550 SMB is built with the following components:

The following list is a list of the actual features that are ordered for DR550 SMB. This list should not be modified in any way as part of the initial order. IBM’s eConfig tool should be used to review any changes in the official configurations. Other configurations are also available.

The following table highlights the versions used in DR550.

An integrated management console is part of the DR550 offering. An as option, limited function is available via a TTY type terminal (customer provided) such as a VT100 or an IBM 3151. The TTY terminal is connected to the P5 520 server(s) via the serial port on the front of the server. It is recommended that the integrated management console be used for all management activity.

An integrated console is part of the DR550 SMB. As an option, limited function is available via a TTY type terminal (customer provided) such as a VT100 or an IBM 3151. If this option is used, the TTY terminal is connected to the serial port on the front of the P5 520 server. It is recommended that the integrated management console be used for all management activity.

Logical Volume Configurations

On the DR550 SMB, LUNs have been configured based on the total storage capacity ordered. All disk capacity is allocated for use by TSM. No disk capacity is set aside for other applications or servers. Below are the LUN configurations set at the factory. If you view the LUN id from AIX, it will be displayed as a hexadecimal address.

AIX settings

The following has been setup for the AIX server(s)

•Paging space has been increased by 1536 MB. Now DR550 SMB has a paging space of 1536 + 512 = 2048 MB paging space.

•Changed TCP parameter in AIX rfc1323 = 1 < the default value was 0.

In addition, FTP and Telnet services have been shut down. All other ports/sockets are blocked with the exception of those needed by AIX, HACMP and Tivoli Storage Manager

The following files have been set at the factory:

1.Defined /tsm/files/devconfig (keeps Tivoli Storage Manager device configuration to help in rebuilding the Tivoli Storage Manager server within DR550 SMB in case of Tivoli Storage Manager server loss).

2.Defined /tsm/files/volhist (keeps track of volumes used by Tivoli Storage Manager).

See the Tivoli Storage Manager for AIX Administrator’s Guide and Reference manuals for information on customizing these settings for your needs.

Tivoli Storage Manager Database and Logs

For the DR550 SMB configuration, a 40 GB logical volume for the TSM database and a 10 GB logical volume for the TSM log have been preconfigured. The Tivoli Storage Manager database and log volumes are configured using RAID5. Tivoli Storage Manager mirroring for the database and log volumes is not configured.

Tivoli Storage Manager Disk Storage Pool

The DR550 SMB has been preconfigured with a single disk storage pool (ARCHIVEPOOL). The raw logical volumes in the table above have been defined into the ARCHIVEPOOL.

Tivoli Storage Manager Storage Management Policy

The DR550 SMB default policy is defined (all are named STANDARD) and the Archive Copy Group in the STANDARD Management Class specifies the following:

Data is stored into ARCHIVEPOOL

A chronological retention policy to retain the data for 365 days

See the Tivoli Storage Manager for AIX Administrator’s Reference, Guide, and Quick Start manual for more information on customizing the Tivoli Storage Manager policy for your data environment.

Automated Tivoli Storage Manager Operations

DR550 SMB includes schedules used to automate Tivoli Storage Manager server administrative commands. The schedules specify that the operations start and stop during defined time periods. You may want to change these start and stop windows to suit your situation. See the TSM for AIX Administrator’s Guide and Reference manuals for help in modifying the administrative schedules.

Examples of schedules that are setup in the DR550 SMB are:

Backup of the Tivoli Storage Manager database is scheduled to run daily at 8am.

Maintain 3 copies of backup and delete older versions (scheduled a job to run daily at 23:59).

Ibm System P5 Serial Connection Baudelaire

Note: It is the responsibility of the customer to set up and verify schedules and database backups. You should verify that you have appropriate schedules in place to back up your database.

Routine Operations for Tivoli Storage Manager

Monitoring the Database and Recovery Log Status

Monitor the Tivoli Storage Manager database and recovery usage log to ensure that you have enough space available for efficient operation. You should pay particular attention to the maximum utilization percentage (%Util) for both. If more room is needed in that database or recovery log, shift resources by using the administrator functions outlined in the Tivoli Storage Manager for AIX Administrator’s Guide and Reference manuals.

Monitoring Disk Volumes

Monitor the status of the volumes for the Tivoli Storage database, recovery log, and the ARCHIVEPOOL storage pool. If any volumes have a status of Offline orStale, you must determine why and correct the situation.

Monitoring the Results of Scheduled Operations

Monitor scheduled administrative to ensure that the schedules are running successfully. This is particularly relevant if you have set up scheduled backups of the Tivoli Storage Manager database.

Installing and Setting Up Tivoli Storage Manager API Clients

The DR550 storage interface is the Tivoli Storage Manager API Client. You may need to install the Tivoli Storage Manager API Client V5.2.2 or later on the server(s) that are sending data to the DR550. Your software vendor may offer specific recommendations for defining Tivoli Storage Manager storage management policies, the Tivoli Storage Manager client node names, and Tivoli Storage Manager client Include-Excludelists. You will also need to point to the network address of the DR550 in the Tivoli Storage Manager Client Communications Options definition.

The following web based education is available from Tivoli and may be beneficial in providing more information on Tivoli Storage Manager for Data Retention. The site for web based training for externals is the Virtual Tivoli Skill Center- cgse1.cgselearning.com/tivoliskills

IBM Tivoli Storage Manager 5.2 Overview and Installation

IBM Tivoli Storage Manager 5.2 Defining Policies; Configuring Database and Recovery Log Volumes IBM Tivoli Storage Manager 5.2 Configuring the Client and Managing Client Data

IBM Tivoli Storage Manager 5.2 Automating Client Operations

IBM Tivoli Storage Manager 5.2 Monitoring and Event Logging Plus Protecting the Database

Classroom instruction is also available.

IBM Tivoli Storage Manager 5.2 Implementation (5 days)

IBM Tivoli Storage Manager 5.2 Total Integration (5 days)

IBM Tivoli Storage Manager 5.2 Update and Migration Topics (2 days)

These courses are expected to be updated for release 5.3 in the future.

Installation and Activation

Safety Notices

A danger notice indicates the presence of a hazard that has the potential of causing death or serious injury. Acaution notice indicates the presence of a hazard that has the potential of causing moderate or minor personal injury.

Note: For a translation of these notices, seeSystem Unit Safety Information, order number SA232652.

Electrical Safety

Observe the following safety instructions any time you are connecting or disconnecting devices attached to the workstation.

DANGER

•An electrical outlet that is not correctly wired could place hazardous voltage on metal parts of the system or the devices that attach to the system. It is the responsibility of the customer to ensure that the outlet is correctly wired and grounded to prevent an electrical shock.

•Before installing or removing signal cables, ensure that the power cables for the system unit and all attached devices are unplugged.

•When adding or removing any additional devices to or from the system, ensure that the power cables for those devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

•Use one hand, when possible, to connect or disconnect signal cables to prevent a possible shock from touching two surfaces with different electrical potentials.

Rs232 Serial Connection

•During an electrical storm, do not connect cables for display stations, printers, telephones, or station protectors for communications lines.

CAUTION: This product is equipped with athree-wirepower cable and plug for the user’s safety. Use this power cable with a properly grounded electrical outlet to avoid electrical shock.

DANGER: To prevent electrical shock hazard, disconnect all power cables from the electrical outlet before relocating the system.

Laser Safety Information

CAUTION: This product contains aCD-ROMand a laser module on a PCI card, which are class 1 laser products.

Laser Compliance

All lasers are certified in the U.S. to conform to the requirements of DHHS 21 CFR Subchapter J for class 1 laser products. Outside the U.S., they are certified to be in compliance with the IEC 825 (first edition 1984) as a class 1 laser product. Consult the label on each part for laser certification numbers and approval information.

CAUTION: All IBM laser modules are designed so that there is never any human access to laser radiation above a class 1 level during normal operation, user maintenance, or prescribed service conditions. Data processing environments can contain equipment transmitting on system links with laser modules that operate at greater than class 1 power levels. For this reason, never look into the end of an optical fiber cable or open receptacle. Only trained service personnel should perform the inspection or repair of optical fiber cable assemblies and receptacles.

Site Preparation and Planning

Before you install the IBM TotalStorage DR550 SMB, we recommend that you consider several things to avoid problems during the installation and configuration. The DR550 SMB comes with preloaded and preconfigured software. No changes should be made to the software during the installation.

The DR550 SMB will ship as separate components. You will need to consider rack requirements, power, cooling and security as you plan the installation. The DR550 SMB requires either 5U or 6U of space in a rack. It is recommended that you place the flat panel monitor in the middle of the rack for ease of use. Locations 21 or 22 are comfortable for many people. You can install the monitor at any location that best meets your needs. The server should be installed within a few EIA units of the monitor. You may want consider installing the server just below the monitor if space is available. I can also go above the monitor if desired. If you have ordered the “tape ready” configuration, then the 2005-H08SAN Switch should be installed immediately between the monitor and server. This is ensure that no warm air is allowed to circulate back to the front of the rack.

You will need to review the available power within the rack. The server requires a single line code, while the monitor requires two line cords (one for the monitor, one for the LCM switch). A single line cord is also required for the SAN Switch.

The table below shows selected factory IP address settings and provides a column to enter the IP addresses to be used later when configuring the DR550 SMB. Other IP addresses within DR550 do not need to be changed.

Refer to Configuring the System (P5 520 Server) section for additional information on IP addresses used for the DR550 SMB.

Cabling to the customer’s Ethernet / IP Network

The DR550 SMB provides for connecting to the customers Ethernet network using either 10/100/1000 copper connections or gigabit fibre connections. For DR550 SMB, only one Ethernet connection is needed. Typically, it is expected that the customer will connect the DR550 to their existing network, including existing customer provided Ethernet switches.

The following diagrams show the connections from an Ethernet perspective. The type of connection (copper or fiber optic) is based on the adapter in the DR550 SMB. This choice is made when the DR550 SMB is ordered.

Ibm System P5

IBM TotalStorage DR550 SMB Version 1.0 ------27 May 2005 Page 18

D is k O n ly

1 0 /1 0 0 /1 0 0 0 (C o p p e r) E th e rn e t / IP C o n n e c tivity

P 5 5 2 0 (D R S _ E n g in e )

S ys te m b o a rd

H M C 1

H M C 2

1 0 /1 0 0 /1 0 0 0 (T 5 )1 0 /1 0 0 /1 0 0 0 (T 6 )

U S B 0 (T 7 )

U S B 1 (T 8 )

C u s to m e r su p p lie d

E th e rn e t c a b le s

1 0 /1 0 0 /1 0 0 0 E N S w itc h # 1

(c u s to m e r's n e tw o rk )

D is k a n d Ta p e R e a d y

G ig a b it (F ib e r O p tic ) E th e rn e t / IP C o n n e c tiv ity

P 5 5 2 0 ( D R S _ E n g in e )

1 0 /1 0 0 /1 0 0 0 (T 5 )1 0 /1 0 0 /1 0 0 0 (T 6 )

U S B 0 (T 7 )

U S B 1 (T 8 )

C u s to m e r s u p p lie d

E th e rn e t c a b le s

G ig a b it E N S w itc h # 1

(c u s to m e r's n e tw o rk )

Setting up the Management Console

DR550 SMB includes an integrated management console. Connections are made through the Netbay LCM (Local Console Manager). To interact with the system software interfaces or to run diagnostics from a DVD-RAM,it is necessary to use the integrated console.

Changing Server Names

You may normally press either the Print Screen key or press theControl key twice to access the OSCAR® (On Screen Configuration and Activity Reporting) interface. To modify the server name on OSCAR, pressPrint Screen and then clickSetup – Names – Modify to access the screen that displays the old name and prompts you to add a new name. Enter a new server name and clickOK in the Modify screen; then clickOK again in the Names screen., If you do not do this the system will be in a suspended state until you press thePrint Screen twice.

Using the Num Lock key and the keypad in OSCAR to soft switch to servers by port number will only work when you first set the Num Lock key for a server. For example, when you setNum Lock on server A, the soft switch to server B and then back to Server A, the LED light on your keyboard will be lit, butNum Lock will no longer be activated for Server A. You can resolve this by pressingNum Lock twice to reset, or avoid it by either using your mouse or the number set on the main part of your keyboard to switch to a different server.

The following diagrams show the connections made in the factory for the DR550 SMB configuration.

Single Node - All Configurations

P5 520 (DRS_Engine)

10/100/1000 (T5)10/100/1000 (T6)

USB0 (T7)

USB1 (T8)

What Is A Serial Connection

Cat 5 cable connected to USB Conversion Option cable (78P5833 - 7316-TF3FC 4269 ) - IBM Supplied

Netbay LCM

7316-TF3Console with KVM switch (FC 4202) and IBM supplied video, keyboard and mouse cables (FC 4242)

As an option, you can attach an external monitor using the serial port on the P5 520. To interact with the system software interfaces or to run diagnostics from a DVD-RAMusing an external device, you will need to do the following:

Nortel Cpmgs Card Serial Connection Baud Rate

•Connect a terminal (or PC) to the serial port FS1 (on the front of the unit) using a null-modemcable (RJ45 to 9 pin Serial cable which is provided by IBM)

Usb To Serial Connection

Your PC may need to use an emulator, such as HyperTerminal, often supplied with Windows family operating systems. Set the emulation mode to vt100 and use the following communication settings:

•19200 baud

•8 bit

Ibm System P5 Serial Connection Baud

•1 stop bit

•No parity

•Xon/Xoff

The following procedure is to connect the ASCII (tty) terminal (or PC) to the P5 520 (this is provided as information only as it is recommended that you use the integrated console for all DR550 management activity:

1.Before doing this step, read and understand “Read the Safety Notices”.

2.This system drawer is equipped with serial port 1 located in the front (FS1) and rear (S1) of the system.

3.Use an RJ-45to9-pinserial null modem cable (IBM supplied) to connect to the front serial port FS1.

4.When using FS1, the rear serial port 1 is deactivated.
